FLX Workbench

BACK-TO-BACK FLEXIBLE BENCH

Formaspace FLX is a component welded, steel framed lab bench that ships knock-down (flat packed for easier shipping). It assembles with only 6 bolts! This flexible services lab bench is a game changer for the industry because it was designed & engineered specifically to address common issues in the lab environment. Visible electrical cords are hidden along with services in wire management troughs. FLX is designed to work with overhead service panels and routing service lines from above or below. Single configuration parts are designed to be universal for ease of use and installation. Back-to-back configurations require only a worksurface and a support frame with 2 legs. The FLX system will help reduce cost in both freight and installation while maximizing space & efficiency. Labs with FLX can be repurposed and reconfigured quickly & easily.

MODIFIERS

Custom configure your FLX lab bench through shelving, surfaces, cabinetry, and parts.

  • Front & rear legs are height adjustable with adjustable leg kits. Overall height is 84”
  • Worksurface height range of 30” to 42” using adjustable legs.
  • 3 depths of worksurfaces (24”, 30”, 36”) & 3 widths of workbenches(48”, 60”, 72”).
  • Adjustable shelves using slotted brackets.
  • Adding back-to-back users is optional & cost effective.
  • Ships knock-down (flat packed) for reduced freight cost.
  • Ease of routing services from above or below.
  • Power is routed in the unit & requires a power strip.
  • Wire management included via wire troughs (2 above, 1 below).
  • Services & wire management troughs also serve as rear spreaders.
  • Designed to work with overhead service panels.
  • 9 countertop & 16 powder coat finish options.
  • Easy installation and reconfiguration.

ACCESSORIES

Add accessories to your FLX bench to increase system functionality.
Power Strip | Monitor Arm | Sink | Faucet | Grommet | CPU Bracket | Light
